Drill Bit

Diameter

No x button diameter

Flushing hole

Weight approx kg

 P/N

mm

inch

Front

Gauge

Angle

Front

Side

32

1 1/4

1X8

3X8

35°

1

2

0.24

BCS32-11-1

32

1 1/4

2X7

5X7

40°

1

1

0.24

BCS32-11-2

33

1 19/64

2X7

4X7

40°

1

1

0.25

BCS33-11

34

1 1/32

2X7

4X7

40°

1

1

0.29

BCS34.11

35

1 3/8

2X7

5X7

35°

1

1

0.33

BCS35-11-1

35

1 3/8

2X7

5X8

35°

1

1

0.33

BCS35-11-2

36

1 27/64

1X8

3X9

40*

1

1

0.36

BCS36-11-1

36

1 27/64

2X7

4X7

40°

1

1

0.36

BCS36-H-2

36

1 27/64

2X7

5X8

35°

1

1

0.36

BCS36-11-3

38

1 1/2

1X9

3X9

40°

1

1

0.39

BCS38-11-1

38

1 1/2

2X8

3X9

40°

1

1

0.39

BCS38-11-2

38

11/2

2X7

5X8

35°

1

1

0.39

BCS38-11-3

38

1 1/2

2X7

5X9

35°

1

1

0.39

BCS38-11-4

40

1 37/64

1X9

3X9

40°

1

1

0.40

BCS40-11-1

40

1 37/64

2X8

3X9

40°

1

1

0.40

BCS40-11-2

40

1 37/64

2X9

3X9

40°

1

2

0.40

BCS40-11-3

40

1 37/64

2X7

5X9

35°

1

1

0.40

BCS40-11-4

40

1 37/64

2X8

5X9

35°

1

1

0.40

BCS40-11-5

41

1 5/8

2X7

5X9

35°

1

1

0.41

BCS4M1-1
